Quick Escape Window
Quick Escape Window
Secure Yet Accessible — When Every Second Counts
Protecting your home shouldn’t mean feeling confined. In an emergency, every moment matters — you need a fast and reliable way out. That’s why MESHTEC™ developed the Quick Escape Security System — a smart solution that combines the proven strength of Genuine MESHTEC™ Screen with a quick, intuitive exit feature.
From the outside, it appears as a fixed security panel — maintaining the clean, secure look of your home. But on the inside, it’s engineered for action. The Quick Escape Window opens easily without a traditional lockset, giving you instant access when you need it most.
With a dual-action release system and an integrated Child Guard, it ensures rapid escape for adults while preventing unintended use by young children — providing both safety and peace of mind.
Strong, simple, and safe — MESHTEC™ ’s Quick Escape System helps you stay protected without ever feeling trapped.
Technical Specification
| Frame | 6063 T5 Alluminium Alloy |
| Mesh | High Tensile Stainless Steel 304 Grade or 316 Marine Grade |
| Wire Diameter | 0.8mm/0.9mm |
| Retention System | Patented MESHTEC™ System |
| Aperture Size | 1.6mm/1.7mm |
| Open Area/Air Flow | 42% |
| Viewing Angle | 156 degrees |
| Lockset | Openable without hardware lockset Dual action release with Child Guard Protection |
| Security Screen Australian Standard 5039 Tested and Certified |
Yes |
| Cut Resistance Knife Shear Test |
Pass |
| Impact Resistance Dynamic Impact Test |
Pass |
| Pry Resistance Jemmy Test |
Pass |
| Mosquito Protection | 98% |
| Powder Coating | Polyester Poder Coating |
| Corrosion Resistance | High Corrosion Resistance Surpass Salt Spray Test 3000hours |
Performance and Testing
| PERFORMANCE | STANDARD |
|---|---|
| Large Missile test | ASTM E 1886 |
| Cyclone Test | AS/NZS 1170.2 |
| Tensile Strength | JIS Z 2241:2011 |
| Spectrometer | ASTM E1086 |
| Knife Shear Resistance | AS 5039.1/AS 5039.3/AAMA1901-25 |
| Dynamic Impact Resistance | AS 5039.1/AS 5039.3/SMA 6001/AAMA1901-25 |
| Jemmy Resistance | AS 5039.1/AS 5039.3/SMA 6001/AAMA1901-25 |
| SAG test | SMA 6001 |
| Corrosion Resistance (Salt Spray) | ASTM B117-11 |
| Powder Coating | QUALICOAT ASTM B117 AS3715/ISO2813, AS2331/ISO2360 ISO1519 ASTM D 2794 |
| QUV weathering | ASTM D 4587 ASTM D 5894 |
| UV Reduction | LUX Intensity Test |
| Temperature Reduction | Solar Heat Test |
| Hardware Durability | AS 4145.2 |
| Mosquito proof | Mosquito protection test (CMU Lab) |
Benefit of MESHTEC™ Quick Escape Screens
Inspiration
Stainless Steel Mesh Powder Coating
MESHTEC™ is proud to be the first and only Interpon D Platinum Approved Applicator for stainless steel substrates, a prestigious certification awarded by AkzoNobel that underscores our commitment to superior quality and performance.
Aluminium Profile 9 Standard Colors
Warranty
