Vandal Protection Screen
Vandal Protection Screen
Proven Strength. Uncompromised Security.
When you need protection that goes beyond standard screens, MESHTEC™ ’s Vandal Protection Screen delivers superior defense against forced entry and vandalism. Engineered with high-tensile stainless steel mesh, this advanced screen solution provides reliable, security-grade performance for commercial, public, and residential applications.
When you need protection that goes beyond standard screens, MESHTEC™ ’s Vandal Protection Screen delivers superior defense against forced entry and vandalism. Engineered with high-tensile stainless steel mesh, this advanced screen solution provides reliable, security-grade performance for commercial, public, and residential applications.
MESHTEC™ Vandal Protection Screens provide more than just a barrier—they offer peace of mind. Combining architectural design with uncompromising strength, they’re the first choice for serious security without sacrificing visibility or ventilation.
Ideal Applications:
• Schools, hospitals, and government buildings
• Public housing and high-traffic urban areas
• Commercial storefronts and entryways
• Homes requiring enhanced protection in exposed locations
• Schools, hospitals, and government buildings
• Public housing and high-traffic urban areas
• Commercial storefronts and entryways
• Homes requiring enhanced protection in exposed locations
Technical Specification
| Frame | 6063 T5 Alluminium Alloy |
| Mesh | High Tensile Stainless Steel 304 Grade or 316 Marine Grade |
| Wire Diameter | 0.8mm/0.9mm |
| Retention System | Patented MESHTEC™ System |
| Aperture Size | 1.6mm/1.7mm |
| Open Area/Air Flow | 42% |
| Viewing Angle | 156 degrees |
| Lockset | European 3-Point Lock |
| Security Screen Australian Standard 5039 Tested and Certified |
Yes |
| Cut Resistance Knife Shear Test |
Pass |
| Impact Resistance Dynamic Impact Test |
Pass |
| Pry Resistance Jemmy Test |
Pass |
| Mosquito Protection | 98% |
| Powder Coating | Polyester Poder Coating |
| Corrosion Resistance | High Corrosion Resistance Surpass Salt Spray Test 3000hours |
Applications
Hinged Door
French Door and Window
Sliding Door and Window
Bi-fold Door
Hinged Window
Awning Window
Double Hung Window
Fixed Window
Performance and Testing
| Header | Header |
|---|---|
| Tensile Strength | JIS Z 2241:2011 |
| Spectrometer | ASTM E1086 |
| Knife Shear Resistance | AS 5039.1/AS 5039.3/AAMA1901-25 |
| Dynamic Impact Resistance | AS 5039.1/AS 5039.3/SMA 6001/AAMA1901-25 |
| Jemmy Resistance | AS 5039.1/AS 5039.3/SMA 6001/AAMA1901-25 |
| SAG test | SMA 6001 |
| Corrosion Resistance (Salt Spray) | ASTM B117-11 |
| Powder Coating | QUALICOAT ASTM B117 AS3715/ISO2813, AS2331/ISO2360 ISO1519 ASTM D 2794 |
| QUV weathering | ASTM D 4587 ASTM D 5894 |
| UV Reduction | LUX Intensity Test |
| Temperature Reduction | Solar Heat Test |
| Hardware Durability | AS 4145.2 |
| Mosquito proof | Mosquito protection test (CMU Lab) |
Benefit of MESHTEC™ Vandal Protection Screens
Inspiration
Stainless Steel Mesh Powder Coating
MESHTEC™ is proud to be the first and only Interpon D Platinum Approved Applicator for stainless steel substrates, a prestigious certification awarded by AkzoNobel that underscores our commitment to superior quality and performance.
Aluminium Profile 9 Standard Colors
